ICESNOW 1Ton/Day Saltwater Industrial Flake Ice Machine For Trawler Fishing

Short Description:

1. Higher refrigeration efficiency and lower loss of refrigeration capacity.

2. Automatic salt water flake ice machine adpots the latest vertical evaporator with inner helix ice cutter. In the process of ice making, the water distribution device in ice maker sprays water even on the internal surface of ice maker to frozen in a short time . After ice formed , the helix ice cutter drops down and cut ice . In this method, it makes a full use of evaporator and increase the efficiency of ice making.

3. High quality , dry and no-caked. The thickness of flake ice which produced by automatic ice flake making machine with vertical evaporator is about 1 mm to 2 mm. The ice shape is irregular flake ice and it has good mobility.

4. Adopt SUS316 stainless steel, effectively prevent seawater corrosion.

Product Detail

Product Tags

Main Features

1.What is the daily capacity of flake ice machine?

0.5tons to 60 tons per day

2.How thick is the flake ice?

from 1mm to 2.2mm with excellent cooling performance

3 .What is the power consumption for this machine?

around 80 kw.h per ton of ice

4.Whether it can use sea water to make flake ice?

yes, it can supply fresh water and sea water flake ice machine. machine can install in the land or on board

5.Whether the spare parts are easy to find in locally?

yes, we use famous and steady refrigeration components and it is also common model in locally and way to find and replace.

Product Decription:

1 tons 24 hrs seawater flake ice machine is widely used in seaport for fish cooling. For its special design and completely stainless steel material used to prevent to machine from corrosion, and the instability due to the unfavorable condition and ship swaying in the sea.

On the fishing, the machines make ice from seawater directly, and also make the heat exchange via the condenser. The low temperature seawater as well as its salinity, makes the ice at an excellent ice degree, to give better fresh keeping for the fish.


Product Advantage:

1.Worldwide famous main ice accessories:

Compressor: main refrigeration system power components ( American Copeland ZB series--High efficiency ,

low noise, built-in discharging valve and temperature Protector)

2.PLC controller: Korea LG;

3.American Expansion valve: (1)Reduce the high pressure and throttle the cold liquid refrigerant from the side with

high pressure, Making it a low temperature low pressure gas-liquid mixing refrigerants; (2) Control the refrigerant flow into the evaporator to adjust cooling capacity of the system and adapt to the change of external load.

4.Schneider AC relay, etc.



1. What's the voltage of the ice machine?

Answer: Standard voltage: 380V-50Hz-3phase, other speccial voltage can be customized also, like: 220V-60Hz-3pase, 415V-50Hz-3phase, 480V-60Hz-3phase.

2. How about the cooling way?

Answer: Usually small ice machines are air cooling, medium and large ice machines are water cooling.

3. What kind of compressor do you use?

Answer: We use international famous brand compressors.

4. How about the payment terms?

Answer: 40%TT in advance and balance before shipment.
