ICESNOW 500kg/Day Flake Ice Machine with stainless steel
1. Daily Capacity: 500kg/24 hrs
2. Machine power supply: 3P/380V/50HZ,3P/380V/60HZ,3P/440V/60HZ
3. The equipment can be used with stainless steel ice storage bins or polyurethane ice storage bins, and a wide range of accessories are available.
4. Flake ice is an irregular piece of ice, which is dry and clean, has a beautiful shape, is not easy to stick together, and has good fluidity.
5. The thickness of flake ice is generally 1.1mm-2.2mm, and it can be used directly without using a crusher.
1 .flake ice Evaporator Drum: Use Stainless Steel material or Carbon Steel Chrominum. The scratch-style of inside machine ensures constant running at the lowest power consumption.
2.Thermal insulation: foaming machine filling with imported polyurethane foam insulation. Better effect.
3. High quality , dry and no-caked. The thickness of flake ice which produced by automatic ice flake making machine with vertical evaporator is about 1 mm to 2 mm. The ice shape is irregular flake ice and it has good mobility.
4. Ice blade: made of SUS304 material seamless steel tube and formed through only one time process. It's durable.
|
Name |
Technical Data |
|
Ice production |
500kg/24h |
|
Refrigeration capacity |
2801 Kcal/h |
|
Evaporating temp. |
-20℃ |
|
Condensing Temp. |
40℃ |
|
Ambient Temp. |
35℃ |
|
Inlet water Temp. |
20℃ |
|
Total Power |
2.4kw |
|
Compressor Power |
3HP |
|
Reducer Power |
0.18KW |
|
Water pump Power |
0.014KW |
|
Brine Pump |
0.012KW |
|
Standard Power |
3P-380V-50Hz |
|
Inlet water pressure |
0.1Mpa－0.5Mpa |
|
Refrigerant |
R404A |
|
Flake ice Temp. |
-5℃ |
|
Feeding water tube size |
1/2" |
|
Net weight |
190kg |
|
Dimension of flake ice machine |
1150mm×1196mm×935mm |
1. Long history: Icesnow has 20 years of ice machine production and R&D experience
2. Easy operation: Fully automatic operation using PLC programmable control system, stable performance, easy operation of ice maker, one key to start, no person need monitor the ice machine
3. Pass the international CE, SGS, ISO9001 and other certification standards, the quality is reliable.
4. Higher refrigeration efficiency and lower loss of refrigeration capacity.
5. Simple structure and small land area .
1). Supermarket preservation: Keep the food and vegetable fresh and beautiful.
2). Fishery industry: Keeping Fish fresh during sorting, shipping and retailing,
3). Slaughtering industry: Maintain temperature and keep the meat fresh.
4). Concrete construction: Reduce the temperature of concrete during mixing, making the concrete more easy to composite.
